HT4001L Analytical Configuration #1	HT4002L Analytical Configuration #2	HT4003L Biocompatible Configuration	HT4004L UHPLC Configuration	HT4005L Large Volume Configuration	HT4001LC Cooling version
Tray	176 positions 2ml vial	176 positions 2ml vial	176 positions 2ml vial	176 positions 2ml vial	96 positions 4ml vial	121 positions 2ml vial
Syringe Default (Supported range)	.1ml (0.1 – 10ml)	.5ml (0.1 – 10ml)	.5ml Needle PTFE tipped (0.1 – 10ml)	.1ml (0.01 – 0.1ml)	2.5ml (0.1 – 10ml)	.1ml (0.1 – 10ml)
Solvent module(s)	4x10ml Vial	4x10ml Vial	4x10ml Vial	4x10ml Vial	3 Nozzle	7x10ml Vial
Waste module(s)	1x100ml  Bottle	1x100ml  Bottle	1x100ml  Bottle	1x100ml  Bottle	Infinite Waste w/internal & external needle cleaning	1x100ml  Bottle
Injection module (Max Pressure)	Valve: HPLC SS/6-2/0.40mm (40Mpa)	Valve: HPLC SS/6-2/0.40mm (40Mpa)	Valve: HPLC PEEK/6-2/0.40mm (40Mpa)	Valve: UHPLC 6-2/0.25mm (100Mpa)		Valve: HPLC SS/6-2/0.40mm (40Mpa)
Loop	20µL (SS)	100µL (SS)	100µL (PEEK)	5µL (SS)		20µL (SS)
